## 9.7. Arrays

Recall that arrays are ordered collections of data elements of the same type that are contiguously stored in memory. Statically allocated single dimension arrays have the form `Type arr[N]` where `Type` is the data type, `arr` is the identifier associated with the array, and `N` is the number of data elements. Declaring an array statically as `Type arr[N]` or dynamically as `arr = malloc(N*sizeof(Type))` allocates N x `sizeof`(Type) total bytes of memory.

To access the element at index i in array `arr`, use the syntax `arr[i]`. Compilers commonly convert array references into pointer arithmetic prior to translating to assembly. So `arr+i` is equivalent to `&arr[i]` and `*(arr+i)` is equivalent to `arr[i]`. Since each data element in `arr` is of type `Type`, `arr+i` implies that element i is stored at address `arr + sizeof(Type) * i`.

Table 1 outlines some common array operations and their corresponding assembly instructions. In the examples that follow, suppose we declare an `int` array of length `10` (e.g. `int arr[10]`). Assume register `x1` stores the address of `arr`, register `x2` stores the `int` value `i` and register `x0` represents some variable `x` (also of type `int`). Recall that `int` variables take up `4` bytes of space, while `int *` variables take up `8` bytes of space.

Table 1. Common array operations and their corresponding assembly representations.
Operation Type Assembly Representation

`x = arr`

int *

`mov x0, x1`

`x = arr[0]`

int

`ldr w0, [x1]`

`x = arr[i]`

int

`ldr w0, [x1, x2, LSL, #2]`

`x = &arr[3]`

int *

`add x0, x1, #12`

`x = arr+3`

int *

`add x0, x1, #12`

`x = *(arr+5)`

int

`ldr w0, [x1, #20]`

Note that to access element `arr[5]` (or `*(arr+5)` using pointer arithmetic) the compiler performs a memory lookup on address `arr*5*4` instead of `arr*5`. To understand why this is necessary, recall that any element at index i in an array is stored at address `arr + sizeof(Type) * i`. The compiler must therefore multiply the index by the size of the data type (in this case `4`, since `sizeof(int)=4`) to compute the correct offset. Recall also that memory is byte-addressable; offsetting by the correct number of bytes is the same as computing an address.

As an example, consider a sample array (`array`) with ten integer elements ([FigArray6]):

Figure 1. The layout of a ten-integer array in memory. Each ai-labeled box represents an offset of 4 bytes, as each integer requires 4 bytes to store.

Notice that since `array` is an array of integers, each element takes up exactly four bytes. Thus, an integer array with ten elements consumes 40 bytes of contiguous memory.

To compute the address of element 3, the compiler multiplies the index 3 by the data size of the integer type (4) to yield an offset of `12` (or `0xc`). Sure enough, element 3 in Figure 1 is located at byte offset a12.

Let’s take a look at a simple C function called `sumArray()` that sums up all the elements in an array:

``````int sumArray(int *array, int length) {
int i, total = 0;
for (i = 0; i < length; i++) {
total += array[i];
}
}``````

The `sumArray()` function takes the address of an array and the array’s associated length and sums up all the elements in the array. Now take a look at the corresponding assembly of the `sumArray()` function:

```Dump of assembler code for function sumArray:
0x874 <+0>:   sub    sp, sp, #0x20          // grow the stack by 32 bytes (new frame)
0x878 <+4>:   str    x0, [sp, #8]           // store x0 at sp + 8 (array address)
0x87c <+8>:   str    w1, [sp, #4]           // store w1 at sp + 4 (length)
0x880 <+12>:  str    wzr, [sp, #28]         // store 0 at sp + 28  (total)
0x884 <+16>:  str    wzr, [sp, #24]         // store 0 at sp + 24 (i)
0x888 <+20>:  b      0x8b8 <sumArray+68>    // goto <sumArray+68>
0x88c <+24>:  ldrsw  x0, [sp, #24]          // x0 = i
0x890 <+28>:  lsl    x0, x0, #2             // left shift i by 2 (i << 2, or i*4)
0x894 <+32>:  ldr    x1, [sp, #8]           // x1 = array
0x898 <+36>:  add    x0, x1, x0             // x0 = array + i*4
0x89c <+40>:  ldr    w0, [x0]               // w0 = array[i]
0x8a0 <+44>:  ldr    w1, [sp, #28]          // w1 = total
0x8a4 <+48>:  add    w0, w1, w0             // w0 = total + array[i]
0x8a8 <+52>:  str    w0, [sp, #28]          // store (total + array[i]) in total
0x8ac <+56>:  ldr    w0, [sp, #24]          // w0 = i
0x8b0 <+60>:  add    w0, w0, #0x1           // w0 = w0 + 1 (i+1)
0x8b4 <+64>:  str    w0, [sp, #24]          // store (i + 1) in i (i.e. i+=1)
0x8b8 <+68>:  ldr    w1, [sp, #24]          // w1 = i
0x8bc <+72>:  ldr    w0, [sp, #4]           // w0 = length
0x8c0 <+76>:  cmp    w1, w0                 // compare i and length
0x8c4 <+80>:  b.lt   0x88c <sumArray+24>    // if (i < length) goto <sumArray+24>
0x8c8 <+84>:  ldr    w0, [sp, #28]          // w0 = total
0x8cc <+88>:  add    sp, sp, #0x20          // revert stack to original state
0x8d0 <+92>:  ret                           // return (total)```

When tracing the above assembly code, consider whether the data being accessed represents a pointer or a value. For example, the instruction at `<sumArray+12>` results in stack location `sp + 28` containing a variable of type `int` which is initially set to `0`. In contrast, the argument stored at location `sp + 8` is the first argument to the function (`array`) which is of type `int *` and corresponds to the base address of the array. A different variable (which we call `i`) is stored at location `sp + 24` and is initially set to 0.

The astute reader will notice a previously unseen instruction at line `<sumArray+30>` called `ldrsw`. The `ldrsw` instruction stands for "load register signed word" and converts the 32-bit `int` value stored at `sp + 24` to a 64-bit integer value and stores it in `x0`. This operation is necessary because the instructions that follow perform pointer arithmetic. Recall that on 64-bit systems, pointers take up 8 bytes of space. The compiler’s use of `ldrsw` simplifies the process by ensuring that all data are stored in full 64-bit registers instead of their 32-bit components.

Let’s take a closer look at the seven instructions between locations `<sumArray+28>` and `<sumArray+52>`:

```0x890 <+28>:  lsl    x0, x0, #2             // left shift i by 2 (i << 2, or i*4)
0x894 <+32>:  ldr    x1, [sp, #8]           // x1 = array
0x898 <+36>:  add    x0, x1, x0             // x0 = array + i*4
0x89c <+40>:  ldr    w0, [x0]               // w0 = array[i]
0x8a0 <+44>:  ldr    w1, [sp, #28]          // w1 = total
0x8a4 <+48>:  add    w0, w1, w0             // w0 = total + array[i]
0x8a8 <+52>:  str    w0, [sp, #28]          // store (total + array[i]) in total```

The compiler uses the `lsl` to perform a left shift on the value `i` stored in `x0`. Once this instruction completes execution, register `x0` contains `i << 2`, or `i * 4`. At this point, `x0` contains the number of bytes to calculate the correct offset of `array[i]` (or `sizeof(int) = 4`).

The next instruction (`ldr x1, [sp, #8]`) loads the first argument to the function (i.e. the base address of `array`) into register `x1`. Adding `x1` to `x0` in the next instruction causes `x0` to contain `array+i*4`. Recall that the element at index i in `array` is stored at address `array + sizeof(T) * i` Therefore, `x0` now contains the assembly level computation of address `&array[i]`.

The instruction at `<sumArray+40>` dereferences the value located at `x0`, placing the value `array[i]` into `w1`. Notice the use of the component register `w1`, since `array[i]` contains a 32-bit `int` value! In contrast, the variable `i` was changed to a 64-bit integer on line `<sumArray+24>` since `i` was about to be used for address computation. Again, addresses (pointers) are stored as 64-bit words.

The last three instructions between `<sumArray+44>` and `<sumArray+52>` load the current value of `total` into component register `w1`, adds `array[i]` to it and stores the result in component register `w0`, before updating total at location `sp + 28` with the new sum. Therefore, the seven instructions between `<sumArray+28>` and `<sumArray+52>` are equivalent to the line `total += array[i]` in the `sumArray()` function.
