7.7. Arrays

Recall that arrays are ordered collections of data elements of the same type that are contiguously stored in memory. Statically allocated single dimension arrays have the form Type arr[N] where Type is the data type, arr is the identifier associated with the array, and N is the number of data elements. Declaring an array statically as Type arr[N] or dynamically as arr = malloc(N * sizeof(Type)) allocates N x sizeof(Type) total bytes of memory.

To access the element at index i in array arr, use the syntax arr[i]. Compilers commonly convert array references into pointer arithmetic prior to translating to assembly. So arr+i is equivalent to &arr[i], and *(arr+i) is equivalent to arr[i]. Since each data element in arr is of type Type, arr+i implies that element i is stored at address arr + sizeof(Type) * i.

Table 1 outlines some common array operations and their corresponding assembly instructions. In the examples that follow, suppose we declare an int array of length 10 (e.g. int arr[10]). Assume register %rdx stores the address of arr, register %rcx stores the int value i and register %rax represents some variable x (also of type int). Recall that int variables take up 4 bytes of space, while int * variables take up 8 bytes of space.

Table 1. Common array operations and their corresponding assembly representations.
Operation Type Assembly Representation

x = arr

int *

mov %rdx, %rax

x = arr[0]


mov (%rdx), %eax

x = arr[i]


mov (%rdx, %rcx,4), %eax

x = &arr[3]

int *

lea 0xc(%rdx), %rax

x = arr+3

int *

lea 0xc(%rdx), %rax

x = *(arr+5)


mov 0x14(%rdx), %eax

Pay close attention to the type of each expression in Table 1. In general, the compiler uses mov instructions to dereference pointers and the lea instruction to compute addresses.

Notice that to access element arr[3] (or *(arr+3) using pointer arithmetic) the compiler performs a memory lookup on address arr+3*4 instead of arr+3. To understand why this is necessary, recall that any element at index i in an array is stored at address arr + sizeof(Type) * i. The compiler must therefore multiply the index by the size of the data type (in this case 4, since sizeof(int) = 4) to compute the correct offset. Recall also that memory is byte-addressable; offsetting by the correct number of bytes is the same as computing an address. Lastly, since int values require only 4 bytes of space, they are stored in component register %eax of register %rax.

As an example, consider a sample array (array) with ten integer elements (Figure 1):

Each integer in the array requires four bytes.
Figure 1. The layout of a ten-integer array in memory. Each xi-labeled box represents 4 bytes.

Notice that since array is an array of integers, each element takes up exactly four bytes. Thus, an integer array with ten elements consumes 40 bytes of contiguous memory.

To compute the address of element 3, the compiler multiplies the index 3 by the data size of the integer type (4) to yield an offset of 12 (or 0xc). Sure enough, element 3 in Figure 1 is located at byte offset x12.

Let’s take a look at a simple C function called sumArray() that sums up all the elements in an array:

int sumArray(int *array, int length) {
    int i, total = 0;
    for (i = 0; i < length; i++) {
        total += array[i];
    return total;

The sumArray() function takes the address of an array and the array’s associated length and sums up all the elements in the array. Now take a look at the corresponding assembly of the sumArray() function:

0x400686 <+0>:	push %rbp                   # save %rbp
0x400687 <+1>:	mov  %rsp,%rbp              # update %rbp (new stack frame)
0x40068a <+4>:	mov  %rdi,-0x18(%rbp)       # copy array to %rbp-0x18
0x40068e <+8>:	mov  %esi,-0x1c(%rbp)       # copy length to %rbp-0x1c
0x400691 <+11>:	movl $0x0,-0x4(%rbp)        # copy 0 to %rbp-0x4 (total)
0x400698 <+18>:	movl $0x0,-0x8(%rbp)        # copy 0 to %rbp-0x8 (i)
0x40069f <+25>:	jmp  0x4006be <sumArray+56> # goto <sumArray+56>
0x4006a1 <+27>:	mov  -0x8(%rbp),%eax        # copy i to %eax
0x4006a4 <+30>:	cltq                        # convert i to a 64-bit integer
0x4006a6 <+32>:	lea  0x0(,%rax,4),%rdx      # copy i*4 to %rdx
0x4006ae <+40>:	mov  -0x18(%rbp),%rax       # copy array to %rax
0x4006b2 <+44>:	add  %rdx,%rax              # compute array+i*4, store in %rax
0x4006b5 <+47>:	mov  (%rax),%eax            # copy array[i] to %eax
0x4006b7 <+49>:	add  %eax,-0x4(%rbp)        # add %eax to total
0x4006ba <+52>:	addl $0x1,-0x8(%rbp)        # add 1 to i (i+=1)
0x4006be <+56>:	mov  -0x8(%rbp),%eax        # copy i to %eax
0x4006c1 <+59>:	cmp  -0x1c(%rbp),%eax       # compare i to length
0x4006c4 <+62>:	jl   0x4006a1 <sumArray+27> # if i<length goto <sumArray+27>
0x4006c6 <+64>:	mov  -0x4(%rbp),%eax        # copy total to %eax
0x4006c9 <+67>:	pop  %rbp                   # prepare to leave the function
0x4006ca <+68>:	retq                        # return total

When tracing the above assembly code, consider whether the data being accessed represents an address or a value. For example, the instruction at <sumArray+11> results in %rbp-0x4 containing a variable of type int which is initially set to 0. In contrast, the argument stored at %rbp-0x18 is the first argument to the function (array) which is of type int * and corresponds to the base address of the array. A different variable (which we call i) is stored at location %rbp-0x8. Lastly, note that size suffixes are included at the end of instructions like add and mov only when necessary. In cases where constant values are involved, the compiler needs to explicitly state how many bytes of the constant are being moved.

The astute reader will notice a previously unseen instruction at line <sumArray+30> called cltq. The cltq instruction stands for "convert long to quad" and converts the 32-bit int value stored in %eax to a 64-bit integer value that is stored in %rax. This operation is necessary because the instructions that follow perform pointer arithmetic. Recall that on 64-bit systems, pointers take up 8 bytes of space. The compiler’s use of cltq simplifies the process by ensuring that all data are stored in 64-bit registers instead of 32-bit components.

Let’s take a closer look at the five instructions between locations <sumArray+32> and <sumArray+49>:

<+32>: lea 0x0(,%rax,4),%rdx       # copy i*4 to %rdx
<+40>: mov -0x18(%rbp),%rax        # copy array to %rax
<+44>: add %rdx,%rax               # add i*4 to array (i.e. array+i) to %rax
<+47>: mov (%rax),%eax             # dereference array+i*4, place in %eax
<+49>: add %eax,-0x4(%rbp)         # add %eax to total (i.e. total+=array[i])

Recall that the compiler commonly uses lea to perform simple arithmetic on operands. The operand 0x0(,%rax,4) translates to %rax*4 + 0x0. Since %rax holds the value i, this operation copies the value i*4 to %rdx. At this point, %rdx contains the number of bytes to calculate the correct offset of array[i] (recall that sizeof(int) = 4).

The next instruction (mov -0x18(%rbp), %rax) copies the first argument to the function (the base address of array) into register %rax. Adding %rdx to %rax in the next instruction causes %rax to contain array+i*4. Recall that the element at index i in array is stored at address array + sizeof(T) * i Therefore, %rax now contains the assembly level computation of address &array[i].

The instruction at <sumArray+47> dereferences the value located at %rax, placing the value of array[i] into %eax. Notice the use of the component register %eax, since array[i] contains a 32-bit int value! In contrast, the variable i was changed to a quad-word on line <sumArray+30> since i was about to be used for address computation. Again, addresses are stored as 64-bit words.

Lastly, %eax is added to the value in %rbp-0x4, or total. Therefore, the five instructions between locations <sumArray+22> and <sumArray+39> correspond to the line total += array[i] in the sumArray() function.
